PH49F

Premium TIZEN-powered displays built to handle any business need in a slim, captivating design

Description

Premium TIZEN-powered displays built to handle any business need in a slim, captivating design

  • All-in-one display solution with embedded MagicInfo Player S4 powered by TIZEN™
  • IP5x certification and non-glare panel to withstand a range of environmental conditions
  • Sleek design with slim depth (29.9mm) and narrow bezels (6.9mm)

Panel

Diagonal Size Class 49
Type 60Hz E-LED BLU
Resolution  1920×1080 (16:9)
Pixel Pitch(mm) 0.560(H) x 0.560(V)
Active Display Area(mm) 1073.779(H) x 604.00(V)
Brightness(Typ.) 700nit
Contrast Ratio(Typ.) 4000:1
Viewing Angle(H/V) 178:178
Response Time(G-to-G) 8ms
Display Colors 10bit Dithering – 1.07Billion
Color Gamut 72%

Mechanical Spec

Dimension (mm) Set 1092.6 x 624.8 x 29.9
Package 1195 X 721 X 167
Weight (kg) Set 13.2
Package 18.1
VESA Mount 400×400
Protection Glass N/A
Stand Type Foot Stand (Optional)
Bezel Width (Top/Side/Bot) (mm) 6.9/6.9/8.9

Operations

Operating Temperature 0℃~ 40℃
Humidity 10~80%
